Wavelength
|
10600nm+/-100nm
|
|
Laser apparatus
|
Sealed off laser device simulated by direct current
|
|
Output power
|
60w
|
|
Spot size
|
0.02~0.05mm2
|
|
Aiming beam
|
Red semiconductor laser (635nm, less than 5mw)
|
|
Beam transport device
|
Articulated arm with 7-joint and balance weight
|
|
Working mode
|
Continuous operation
|
|
Output Mode
|
Continuous, single pulse, interval pulse and super pulse
|
|
Scan scope
|
Less than 20mmx20mm
|
|
Scan graphics
|
Circle, triangle, square, rectangle,hexagon, ellipse, line
|
|
Scanning Mode
|
Sequence , random and maximum distance scan
|
|
Scanning speed
|
More than 10m/s
|
|
Duration
|
1-60w, every 1w is adjustable
|
|
Pulse interval time
|
0~999ms, every 1ms is adjustable
|
|
Modulation Frequency
|
0~999HZ, every 1HZ is adjustable
|
|
Input power
|
450VA
|
|
Cooling system
|
Water and air circulation
|
|
Environment temperature
|
5°C~40°C
|
|
Relative humidity
|
Less than 80%
|
|
Power
|
220V, 50HZ
|
